Battery Scheduling

• Open your AlphaESS app and click on the button on the upper right corner and navigate to “Setting”.



• Select” Charging/Discharging setting” within “Function Setting” page.



• You can schedule two periods for charging/discharging by enabling either "Charge Batteries from Grid (charging)" or "Battery Discharge Time Control (discharging)." After setting the periods, click "Submit" to activate the schedule. Additionally, you can specify when to stop charging or discharging on this page.



• Tap ' Device ' on the bottom banner of the Home page, then select your inverter to access the settings



• Select the ' Time - Based Control ' mode and click ' Edit ' to configure your time settings. Click ' Add Time Period ' to create either a charging or discharging time slot. You can configure the start and end times accordingly, with up to two separate time slots allowed for charging and two for discharging.



• Open your Neovolt app and tap the 'Function' button at the bottom of the home page. Then select 'Charging/Discharging Setting' to begin scheduling.



• Toggle on the 'Charge Batteries from Globird' or 'Battery Discharge Time Control' switch to enable time period settings. You can set up to two time periods for charging or discharging. Additionally, you can specify when to stop charging or discharging by setting a target State of Charge (SOC%).



You can schedule your battery through the Redback portal by following these steps:

• Click the Settings icon in the centre of the homepage.



• Scroll down to the bottom of the page. Under the inverter section, you will see two options. Select "Schedule" to set your battery to charge or discharge based on time. Click "New Schedule" to begin configuration.



• Choose from several scheduling options, including charge, discharge, or conserve mode. You can also set a specific power level (in watts) and define a time period for your schedule.



• After configuring the time and power settings, select whether the schedule should run once or daily. Click "Add Schedule" to complete the setup.



The SAJ app currently doesn’t support scheduling. However, once your battery is successfully connected to us, you can easily control it through the GloBird App. Please refer to the guidance section below for instructions on using the GloBird App.

• Open the “Mysigen” app and tap the “Current Mode” button on the home page.



• Click on the “current mode”, and you will jump to different operational mode options. Choose “Time-based Control” If you would like to schedule



  charge/discharge your battery.

• Click on “Schedule” and choose “Edit” to start your own schedule. You will able to choose from charge/discharge/self-consumption. Don’t forget to save your schedule after setting completed.



• Open your SolaXcloud app and tap on "Device" in the bottom menu. Then, select the device located on the right side.



• Tap on "Remote Settings" and then select "Settings." You'll need to enter an "Unlock Password" to enable the settings function. If you don't have the password, contact your installer for assistance.



• Tap on "User Settings" and expand the "Charge & Discharge Period" to customize your schedule.



• Set your charge and discharge periods by entering the start and end times below. Be sure to tap "Save" to store your settings.



• Once charge time is settled, please back to “self-use” and make sure to "Enable" the "Charge from Grid" option, set the "Charge Battery to" 100%, and tap "Save".



• From the Home screen, select your plant and tap ' Device ' on the top banner. Click on inverter into inverter details.



• Tap the three dots in the top right corner of the inverter details screen, then select ' Storage Mode '



• Click on ' Charge & Discharge Slot ' under the Storage Mode page. You can set up to six time slots for charging or discharging by configuring the time and toggling the ' Enable ' button.



• Open your Isolarcloud app and click on the button on the upper right corner and navigate to “Device”.



• Select "Energy Storage System" and proceed to "Settings" on the following page.



• Navigate to "Energy Management Parameters" within the "Settings" page, where you can adjust your charging and discharging periods for both weekdays and weekends by selecting the desired option.



  You can start setting your schedule by clicking on the start and end times. For weekdays, you can set up to two schedules for discharging, and you also have the option to enable or disable discharging during weekends or force charging. After updating the time, click on "Apply Setting" to activate your schedule.



• Open your Tesla app and click on “Setting” within home page.



• Navigate to the "Utility Rate Plan" option on the "Settings" page. Choose "Start Over" to initiate the schedule creation process or select "Edit" if you've already configured your settings previously.



• You have the option to select either a customer rates plan or fixed rates that best suit your needs. To begin, please fill in the fields for "Utility Provider Name" and "Rate Plan Name."



• Next, you'll be prompted to select the factors influencing your rates and establish your peak/off-peak times according to your weekday and weekend retailer plan. You can easily include additional time periods by selecting "add time period."



• Following that, you'll need to input your electricity costs according to your specific electricity plan. Afterward, by clicking the "next" button, you'll be able to review a summary of your plan. Don't forget to save your plan by clicking the "save" button.



• To activate your plan, revisit the "Settings" section and select "Powerwall." Then, check the box labelled "Time-Based Control" to activate your plan.
